FLYLINE SOLAR ADVERTISEMENT BOARD LIGHT

Murickens solar advertisement board light is used to highlight the advertising material kept on state or national highways or streets and junctions. As this system uses LED lighting system so we can eliminate the installation of costly bulbs, tubes or Cfl. There is no need to convert it to ac current source, so it’s cost effective and long running, it can effetely control the lighting required depending on the weather conditions of that area. It’s automatically turned on or off so there is no manpower required..


Our panels are Central Power Research Institute (CPRI) approved.We have made a place of our own in the field of solar based power units since the installation from 2000 and have done thousands of solar power unit installations in many places including Agricultural University in Malapuram, Government of Kerala,CISF 7th battalion military campin Karipoor Airport, ISRO Sreeharikotta, Marine Fisheries Dept of India, Vallarpadam Container Terminal (IGTPL) etc.it is essential that the installation should be undertake by a well experienced technical person to get 100% out put of the system and avoid unnecessary expenses and for a smooth and trouble free operation. The maximum utulization of solar power consumption is depending up on a thorough follow up of an experienced technical advice

LED BASED SOLAR ADVERTISING BOARD LIGHT FEATURES

►DC volt out put 12V or 24 V. ► It have automatic control system (Dusk to Down). ► It is best solution for lighting public advertising board and banners. ► It is available in 3w, 6w, 9w, 12w, 18w, 21w 24 w, 27w, 30 w, and above. ►By using powerful LED and CFL 100% brightness for the light is guaranteed.► its power consumption is very low and get very good back up. ► No need of wiring, so we can forget the headache of wiring and its expense. ► With the cost of AC cable and wiring, you can install a fly line full light system, with out electricity bill and man power. ► We can charge the battery with the help of solar cell. ► Its Initial cost is also very low. ► No further expense ► Very low maintenance. ►Its Specially designed and well developed control system to protect the whole unit.

MODELS ASSL-3 ASSL-6 ASSL-9 ASSL-12 ASSL-18
Capacity 3 WATT 6 WATT 9 WATT 12 WATT 18 WATT
Lamp / Luminary Type LED LED LED LED LED
Operating Voltage 12 V 12 V 12 V 12 V 12 V
Power Consumption 3.3 6.4 9.9 13.2 19.8
Luminary Equal to 9 W CFL 20W CFL 30W CFL 40 W CFL 60 W CFL
Driver technology Micro Controller Based C.C.C.V.
Lamp Efficiency >90% >90% >90% >90% >90%
Working Temp. 30° C to 50° C
Working Life 50,000 to 1,00,000 Working Hours
Operation Automatic Dusk to Down
IP Rating IP 65
Solar photovoltaic Module 10 W 20 W 50 W 70 W 100 W
Battery Voltage 12 V 12 V 12 V 12 V 12 V
Battery capacity 7 Ah 14 Ah 40 Ah 60 Ah 80 Ah
Battery Type Sealed Lead acid Tubular
Autonomy 1/2 Days
Battery Box M.S. Box with Silver painted/ powder coated
Pole M.S. pole with Silver painted and 4 meter height
Charger Technology Micro controlled PWM Based
Warrantee ONE YEAR
